• Rating：12VDC 50mA
• Travel：0.3mm
• Life：100,000 cycles~1,000,000 cycles
• ontact Resistance：100mΩ MAX Initial
• Insulation Resistance：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：2=180gf 3=260gf
• Operating Temperature：-20℃ ~70℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Operating Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RTS-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSA-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSA-64 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSAL-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSAM-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSM-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSM-64 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTSTL-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
| RTST-6 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.3mm | 100,000 cycles~1,000,000 cycles | -20℃ ~70℃ | 暫無 |
