• Rating：12VDC 50mA
• Travel：0.5±0.3mm
• Life：1,000,000 cycles
• Contact Resistance：100mΩ MAX Initial
• Insulation Resistance：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：250±50gf
• Waterproof Grade：IP67
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Life | Waterproof Grade | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RTSHW6-050-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSMW6-050-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSHW6T-010-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSMW6T-012-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSHW8-010-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSHW10-013-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSMW12-060-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
| RTSHW12-060-□-V | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 250±50gf | 1,000,000 cycles | IP67 | 0.5±0.3mm | 暫無 |
